Fully autonomous high-precision operation
Obstacle avoidance radar
30L effective capacity
Quick release battery
Quick release double tank
IP65 waterproof
Dual FPV real-time monitoring
C30 is equipped with 120° FPV real-time wide-angle cameras at the front and rear, which meets the needs of operation visualization. Equipped with two high-brightness LED searchlights, it is convenient for night work; it is also equipped with an obstacle sensing module, which can predict the obstacles ahead and ensure your flight safety.
C30 adopts the design of eight nozzles and four water pumps. The flow rate of a single water pump can reach 8L/min, and the overall spraying is more uniform.
C30 adopts front and rear obstacle avoidance radar, can fly autonomously without turning it's head. It makes the flight safer.
The wrap around folding structure can minimize the volume of the fuselage after folding, which is convenient for transportation and transition.
The RTK installed on the C30 has centimeter-level positioning capabilities, providing more accurate positioning and safety guarantees for aerial defense operations.
Wheelbase: 1950mm
Product size: 2900×2900×780 mm (with arms extended, blades extended)
2050×1610×780mm (the arm is unfolded, the blade is folded)
1050×620×780mm (the arm is folded)
Total weight of the whole machine: (not including battery) 27.8 kg
Standard take-off weight: 38.3 kg
Maximum take-off weight: 68.3 kg
Hovering accuracy: (Good GNSS signal)
J-RTK enabled: horizontal: ±10 cm, Vertical: ±10 cm
J-RTK not enabled: horizontal ±0.6m, vertical ±0.3 m (Radars enabled: ±0.1 m)
Battery capacity: 14S (22000mAh 51.8V)
Maximum power: 12000 W
Hovering power dissipation: 6150 W (take-off weight 48.5 kg)
Flight duration: 21.10 min (@22000 mAh battery & take-off weight: 38.3 kg)
8.30 min (@22000 mAh battery & take-off weight: 68.3 kg)
Maximum working flight speed: 7 m/s
Maximum flight speed: 10m/s
Maximum wind resistance: 8 m/s
Maximum flight altitude: 2000 m
Recommended working temperature: 0°C ~ 40°C
